S-24V90-TRX
SKU: S-24V90-TRX
S-24V90-TRX PROTRXion® 24V, 90Ah Li-ion Battery Pack
Industry:
Sector:
Medical, Material Handling
Description
PROformance Series Lithium-ion Batteries
Intelligent, robust & high-performing battery solutions for motive applications
- Advanced battery systems designed to work in the toughest and most demanding motive environments
- Available in two models: M-version (standard) and S-version (terminals always active with no heater)
- Advanced BMS with configurable software to optimize safety and performance
- Operates down to -35°C with optional heater
- Global certification (UL, TUV, etc.)
- Modular to support various power requirements
- Advanced balancing technology
Features
- Certified to global functional safety standards
- Fast charging within 2 hours with leading charger OEMs
- Long shelf life performance 24 months from shipment
- Scalable to increase runtime
- Automotive grade cells from top tier manufacturers
- Patented virtual BMS - Single battery platform with advanced modular network
- UL2271 Certified off-road safety for low speed electric vehicles
- Universal Communication Protocol (CANopen)
- State-of-the-art module balancing technology
- Propagation Mitigation
- Supports regenerative braking
Details
| Terminal Configuration: | M8 (Neg), M10 (Pos) |
| Volts: | 24 VDC |
| Battery Capacity: | 90 Ah |
| Length: | 34.8 CM |
| Width: | 17.8 CM |
| Height: | 26 CM |
| Weight: | 20.4 KG |
Construction
- Terminal Type (ISO) M8 (Neg) M10 (Pos)
- Terminal Torque (Nm) 17 ± 1 (Neg) 22 ± 1 (Pos)
- Weight 20.4kg (45.0lbs)
- Installation Orientation Horizontal / Vertical
- Ingress Protection Rating IP67*
- Case Flammability Rating Flame Retardant UL94 V-0
Applications
- Professional Cleaning
- Aerial Work Platform
- Material Handling
- Robotics
Standards
- UL1642 (Cell), UL2271 (Pack)
- UL2271 (Pack)
- IEC62133 (Cell/Pack)
- FCC Class B
- IEC60730 Class B
- UN/DOT 38.3
- ECE R100 / R10
